MaxiSys MS919

$2,999.00 $ 3,800.00

Code: Mx-MS919

Brand: AUTEL

Type: PROGRAMMING TOOL


Add to Cart


How the Autel MS919 differs from the older Elite and MS908s:
More memory: 128GB Memory
 VCI interface with updated J2534 includes oscilloscope, waveform generator, multimeter, CanBUS tester
 Topology M Module Listing CAN BUS Tree
 Faster processor
 Does not include a docking station
Does not include early OBD-II adapters!
 Android 7.0
2-year subscription with renewable warranty.

Features
9.7’’ Touchscreen (1536 x 2048)
-Android 7.0
 2.3GHz + 1.7GHz Octa-core Processor / 256GB Memory
 Advanced VCMI 5-In-1 Device: VCI, Oscilloscope, Multimeter, Waveform Generator, CAN BUS Check
Oscilloscope Preset Guided & Component Tests / Waveform Library
New VCI Protocols: D-PDU, DoIP/CAN FD, Mega CAN
Topology Module Mapping: Color Coded All System Status Screen (on supported vehicles)
 Relevant Cases: DTC Troubleshooting / Repair Tips Video Library
 Repair Assist: Guided Procedures with DTC Analysis & Fault Code Solutions
Code-Related Technical Service Bulletins (on select vehicles)
 License Plate Reader
 ScanVIN: Barcode or Text Recognition with Camera
Secure Gateway Access: Authorized FCA SGM Access with AutoAuth Account (sold separately)
Includes Cables, Scope Connectors, Carrying Case
Enhanced Diagnostic Reports: PreSCAN & PostSCAN
 15000mAh - 8hrs Continuous Use
 16MP Rear Camera & 5MP Front Camera
 2-year Warranty & Software Subscription For GCC.

Specifications

  1. OS Android 7.0
  2. Processor Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)
  3. Memory 4GB RAM & 256GB On-board Memory
  4. Display 9.7 inch TFT-LCD with 1536 x 2048 resolution & capacitive touchscreen
  5. Connectivity WiFix2 (802.11 a/b/g/n/ac 2x2 MIMO)
  6.   BT v.2.1 + EDR
  7.   GPS
  8.   USB 2.0 (Two USB HOST Type A, one USB mini device)
  9.   HDMI 2.0
  10.   SD Card (Support up to 256GB)
  11. Camera Rear: 16 Megapixel, Autofocus with Flashlight
  12.   Front: 5 Megapixel
  13. Sensors Gravity Accelerometer, Ambient Light Sensor (ALS)
  14. Audio Input/Output Microphone
  15.   Dual Speakers
  16.   3-Band 3.5 mm stereo/standard headset jack
  17. Power and Battery 15000mAh 3.8 V lithium-polymer battery
  18.   Charging via 12 V AC/DC power supply with the temperature between 0°C and 45°C
  19. Input Voltage 12V/3A Adapter
  20. Operating Temp. 0 to 50°C (32 to 122°F)
  21. Storage Temperature -20 to 60°C (-4 to 140°F)
  22. Dimensions (WxHxD) 304.4 mm (11.98") x 227.8 mm (8.97") x 42.5 mm (1.67")
  23. Weight 1.66kg (3.66lbs)
  24. Protocols DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can (GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
