AUTEL MAXISYS ADAS Specs:
Manufacturer: AUTEL
Condition: New
Frame capable of performing 4-Wheel alignment and ADAS calibration
Six high-resolution positioning and tracking cameras in frame
Includes 24” touchscreen display that attaches to frame unit
MAXI-SYS software interface monitors and displays alignment measurements
Cameras automatically track vehicle height on shop lift
Robotic frame movement
Alignment coverage includes U.S., Asian and European vehicles, 1996 and newer
Illustrated alignment instructions, live readings, required tools and adjustment locations display on a single screen
Includes four-wheel clamps with camera targets, steering wheel lock and wheel chocks
One-year warranty
AUTEL MAXISYS ADAS IA900AST Wheel Alignment & ADAS System Calibration Frame Specifications :
New AUTEL IA900WA Wheel Alignment & ADAS System Calibration With MSULTRAADAS Tablet Package | Emirates Keys
New AUTEL IA900WA Wheel Alignment & ADAS System Calibration With MSULTRAADAS Tablet Package | Emirates Keys
•24in Touchscreen Monitor
•Simulcast from MAXI-SYS Ultra
•MAXI-SYS Ultra Tablet Cradle With Controls
•MAXI-SYS Interface Instead of PC for Wheel Alignment
•Robotic Frame Movement
•Precise Optical Measurement With 6 High Resolution Cameras
•Self Calibrating Cameras, Always Accurate, Every Time
•Cameras Automatically Track Vehicle Height On Lift
New AUTEL IA900WA Wheel Alignment & ADAS System Calibration With MSULTRAADAS Tablet Package | Emirates Keys
AUTEL MAXI-SYS ADAS IA900AST WHEEL ALIGNMENT SOFTWARE
Vehicle inspection of tires, brakes, suspension, steering, and more. Mark service recommendations, attach photos and notes.
Live alignment reading display.
Illustrated alignment instructions, live readings, required tools, and adjustment locations display on a single screen.
IA900A ADAS CALIBRATION SOFTWARE
The industry’s fastest and most accurate frame placement in as little as a minute.
Step-by-step illustrated full-color instructions walk the user through the ADAS calibration process.
Set ADAS calibration target height with the push of a button.
AUTEL MAXI-SYS ADAS CALIBRATION Compensates for uneven floors in all directions.
FOLDING CROSSBAR
6inch MINIMUM HEIGHT
7inch MAXIMUM HEIGHT
AUTEL ADAS Packages Compare
The New AUTEL IA900WA All ADAS Systems Package, with Alignment System which also includes the MSULTRA Tablet Part Number: IA900AST
The New AUTEL ADAS IA900WA with MSULTRA Tablet Includes:
AUTEL MAXI-SYS MSULTRA Table Diagnostic Scanner Tablet with ADAS Upgrade
MS ULTRA Tablet
ADAS Upgrade Software
1. Pattern Board 0600/06
2. Patterns VW-LDW CSC0601/01 Mercedes-LDW CSC0601/02
3. Volkswagen / Audi / Porsche - LDWI CSC0601/01
4. Sliding Laser Plate
5. Mounted Tape Measure
6. Flip Up Reflector & Laser Position Ruler
7. Crossbar 0600/05
8. Push Button Power Lifter
9. Adjustable Base
10. Base Crossbar 0600/02
11. Base Holder 0600/01
12. ACC Reflector 0602/01
13. Wheel Clamp Lasers 0500/02
14. Wheel Clamps 0500/01
15. Honda - LDW CSC0601/05
16. Honda - LDW CSC0601/08-L
17. Honda - LDW CSC0601/08-R
18. Honda / IA LDW CSC0601/09
19. Nissan / Infiniti-LDW CSC0601/06-L
20. Nissan / Infiniti-LDW CSC0601/06-R
21. Toyota-LDW CSC0601/15
22. Nissan-LDW CSC0601/03-L
23. Nissan-LDW CSC0601/03-R
24. Toyota / Lexus LDW CSC0601/11
25. Mercedes-LDW CSC0601-02
26. Mitsubishi Lane Keep Target Board CSC601/22-L
27. Mitsubishi Lane Keep Target Board CSC601/22-R
28. Target Board Holder 0600/22
29. Cadillac - AVM CSC1004/06
30. Center Axis Laser 0500/04
31. Honda - AVM CSC1004/02
32. Honda - AVM CSC1004/03
33. Nissan - RCW CSC1006/03
34. Mercedes - RCW CSC1006/01
35. VW-RCW CSC0806/01
36. VW-AVM CSC0804/01
37. Radar Calibration Plate 0602/02
38. Radar Calibration Box 0605/01
39. Corner Reflector 0802/01
40. Night Vision Calibration Box 0603/01
41. Night Vision Calibration 0803/01
42. Mercedes Lane Keep Target Board CSC601/19
43. Subaru Lane Keep Target Board CSC601/17
44. Mazda Lane Keep Target Board CSC601/13-L
45. Mazda Lane Keep Target Board CSC601/13-R
46. Nissan Lane Keep Target Board CSC601/03-L
47. Nissan Lane Keep Target Board CSC601/03-R
48. Subaru LDW 3 CSC0601-17 Target Board
49. Alfa Romeo LDW CSC0601-10 Target Board
50. Toyota One Time Recognition LDW CSC0601-25 Target Board
51. Gensis LDW CSC0701-23
52. Mitsubishi AVM CSC1004-09
53. Honda LaneWatch CSC0805-02
54. Target Stand CSC0802
55. Hitachi Radar Plate CSC0802-03
56. Nissan RCW CSC1006-05
57. Toyota-AVM CSC1004-10
58. Hyundai/Kia vehicles equipped with AVM CSC1004/04
59. RCW for Mercedes CSC1006/02
60. VW/Audi ADR Calibration Plate CSC0602/08
61. Toyota LIDAR Reflector CSC802/04
62. VW/Audi LIDAR Calibration Board CSC602/04
63. Used for Toyota/ Lexus vehicles equipped with NVS CSC603/03
64. Nissan/Infiniti vehicles equipped with AVM CSC1004/11
65. Now comes Standard Frame 2.0 AUTEL Frame Distance Measuring Upgrade for Standard Frame
Digital Tape Measure Crossbar Brackets - Holds digital tape measure for faster & more accurate frame placement
Front Wheel Targets - Used with digital tape measures to find accurate distance from front axle
Placement Boards - For use on an alignment lift
Center Digital Tape Measure Bracket - Finds distance from front of car when measuring from emblem/bumper
Digital Tape Measures - Replaces manual tape measure for faster & more accurate frame placement
The AUTEL MAXI-SYS ADAS Calibration Application software provides graphic step-by-step instructions that are vehicle model specific to confirm the correct patterns are used during the correct calibration procedures. Your MAXI-SYS software confirms this information is correct, based on the vehicle information confirmed from the AutoSCAN feature, to confirm which active ADAS modules in any vehicle system may need a calibration procedure completed.
Does the MS ADAS tablet provide other scan tool functions than ADAS calibration?
a. Yes, the MS ADAS provides all the same diagnostic and maintence services as the MS908SP, including Pre / Post Scanning
Do I need a new scan tool for ADAS calibration, if I already have an existing MS908 / MS908P / MS908S / MS908SP / MS908E.
a. You can purchase an ADAS UPGRADE to add ADAS capabilities to your existing AUTEL MAXI-SYS scan tool.
b. If you do not have an AUTEL scan tool, then you should purchase an MSADAS scan tool package for best value.
Can I purchase just the ADAS application upgrade without the calibration frame to complete ADAS calibration procedures?
a. No, the MAXI-SYS ADAS application requires a code (QR code scan) from the calibration frame to activate the software.
For more information, see 'ADAS Frame Banding' on the DOWNLOAD page.
If I want to add individual targets or calibration tools later, are they available for purchase?
a. Yes, the specialty fixtures, existing targets and new vehicle coverage targets are available for individual purchase.
Depending on which vehicle systems I am concerned with, which ADAS calibration kit should I purchase?
a. LDW, LKA, ACC (forward looking only) - You need the LDW kit (ADS-LDWPACKAGE)
b. AVM, RCW, RCA (around view / 360 view / rear looking) - You need the Complete Kit (ADS-ADASCOMPLETE)
c. Night Vision, Radar (includes Blind Spot etc.) - Also in the Complete Kit (ADS-ADASCOMPLETE)
*can be added as additional accessories to the LDW kit
Do I need someone to assemble and or set up the calibration frame?
a. No, the complete assembly is a simple 20-25 minute process. Graphic instruction and standard screws are included.
Are training options necessary for working on ADAS calibrations?
a. No, The MSADAS software features step by step illustrated instructions for placing the calibration frame and targets.
b. If a customer requests general ADAS training, I-CAR, CTI, and ISHAFQ ARIF TOOLS have ADAS classes utilizing the AUTEL tool.
What are insurance companies paying for calibrations?
a. Insurance companies are typically paying between $250 and $400 for each ADAS calibration.
b. The ADAS application also provides the Pre and Post-SCAN features, which insurance companies pay $100-$150 for.
Other than a clear 30 foot x 15 foot area, what are the other working shop bay requirements to complete ADAS calibrations?
a. No obstructions or 2 post lifts. An alignment bay will work if there is approx. 9 1/2’ between the frame and lift
b. Level floor in the bay or the lift being level at 3 foot or lower.
c. No “checker board” or other geometric patterns on the walls or floor
d. Able to close bay door and or block exterior light sources that cast uneven surface shadows
What are the different types of ADAS calibrations and are they brand specific?
Depending on vehicle type, either a Stationary or Dynamic calibration procedure is required (in some vehicle types both are required) to calibrate ADAS sensors to vehicle modules.
• Stationary calibrations are completed in a shop environment and requires the use of targets or patterns to complete.
• Dynamic calibrations require the vehicle to be driven on roadways for a certain amount of time with well-maintained road markings.
Can I activate multiple tool ADAS applications from one calibration frame?
a. No, the activation “bonding” is unique to a single ADAS application tool from the Autel ADAS calibration frame.
b. You can use an “activated” ADAS application tool with any AUTEL ADAS calibration frame.
For more information, see 'ADAS Frame Banding' on the DOWNLOAD page.
Does the MSADAS tablet provide other scan tool functions in addition to ADAS calibration?
a. Yes, the AUTEL MAXI-SYS ADAS Tablet includes all of the diagnostic and maintenance functions as the AUTEL MAXI-SYS MS908SP, including Pre & Post-SCAN reporting and J-2534 programming interface
Can I activate multiple ADAS-Capable tablets with one calibration frame?
a. Yes, you can add multiple ADAS capable tablets to your calibration frame. However, only one type of calibration frame can be activated on each tablet. Be sure to select the correct calibration frame as this selection cannot be un-done and two version of the ADAS software cannot reside on the same tablet.
Can I purchase just the ADASUPGRADE without the calibration frame to perform ADAS calibration procedures?
a. Yes, however, a large portion of vehicles require static calibrations, where special equipment is placed around the vehicles at specified locations. Remember, the tool will ask which type of calibration frame you are using when you add the ADAS software. If you don’t have a calibration frame yet, select the option you would most likely get.
What are the different types of ADAS calibration and are they brand specific?
a. There are two types of ADAS calibration, STATIC and DYNAMIC. The type of calibration required is determined by the vehicle manufacturer.
STATIC CALIBRATIONS are performed in the service bay using vehicle specific targets and patterns. Static calibrations require controlled conditions, such as bright even lighting, flat level floor, no clutter behind the targets, etc.
DYNAMIC CALIBRATIONS are performed while driving the vehicle under very specific conditions determined by the vehicle manufacturer. These conditions include, calibrating during the day, clearly visible lane markings, clear weather conditions, specific driving speeds,flat roads with minimal hills or curves, minimal traffic, etc.
Which vehicle actions require ADAS system dianostics or ADAS sensor calibration?
a. ADAS sensor or camera replacement, collision repair, four wheel alignment, changes in ride height (within vehicle manufacturer’s specifications), windshield replacement, certain mechanical repairs which require the removal of bumper covers, grill, etc., ADAS related diagnostic service, ADAS sensor or camera removed and reinstalled or changes in tire size (within vehicle manufacturer’s specifications).
What is the easiest way to check the vehicle to confirm which ADAS module are active?
a. Performing a Pre-Scan with your AUTEL MAXI-SYS will provide a list of all modules currently communication of the vehicle data network. An ADAS icon will display next to a module with ADAS functionality.
Does the calibration frame require assembly?
a. Yes, frame assembly is a simple 20-25 minute process. Illustrated instructions, hardware and required wrenches are included. We also have an assembly video on the www.maxisysadas.com website.
How do I know what patterns and calibration procedures to use?
a. The AUTEL MAXI-SYS ADAS software displays vehicle specific illustrated step-by-step calibration instructions, which include a list of all needed targets, patterns and accessories required to complete the calibration.
What vehicle preparation is required before performing calibration procedures?
a. The AUTEL MAXI-SYS ADAS software will provide a detailed list of vehicle manufacturer specific calibration preparation instructions. The preparation requirement vary by vehicle make. Some common calibration requirements include:
Vehicle must be parked on flat, level surface
All fluids must be filled to the recommended levels, e.g. oil, coolant, etc.
The fuel tank must be full
Tire pressure must be set to placard level
No passengers or additional load in the vehicle
All doors and hood must be closed
Connect an auxiliary battery power supply
How do I know if the ADAS recalibration was successful?
a. At the end of the calibration procedure the AUTEL MAXI-SYS will display a screen indicating the calibration completed successfully. It is a good idea to perform a screenshot at this point and attach this screen to your post scan report. On some vehicle makes calibration parameters will be added to the post-SCAN report which indicate the accuracy of the calibration.
Full Description:
Autel MAXISYS ADAS IA900AST Wheel Alignment + ADAS System Calibration Frame + All Systems Targets With MaxiSys Ultra Diagnostic Scanner
Autel MAXISYS ADAS Product Description:
The MaxiSYS IA900AST Wheel Alignment and ADAS calibration frame enables the performance of four-wheel alignment and ADAS component calibration. Software includes Illustrated alignment instructions, live readings, required tools, and adjustment locations display on included 24” touchscreen screen. Alignment coverage for U.S., Asian and European vehicles, 1996 and newer. Six high-resolution positioning and tracking cameras in frame automatically monitor vehicle height on shop lift. Robotic frame movement for efficient use and alignment reading accuracy to 0.02 degrees for precise alignments. Includes steering wheel lock and wheel chocks.
Diagnostic Tools From AUTEL with Product Number: MK19400
This Weight Product: 520000g
AUTEL MAXISYS ADAS Specs:
Manufacturer: AUTEL
Condition: New
Frame capable of performing 4-Wheel alignment and ADAS calibration
Six high-resolution positioning and tracking cameras in frame
Includes 24” touchscreen display that attaches to frame unit
MAXI-SYS software interface monitors and displays alignment measurements
Cameras automatically track vehicle height on shop lift
Robotic frame movement
Alignment coverage includes U.S., Asian and European vehicles, 1996 and newer
Illustrated alignment instructions, live readings, required tools and adjustment locations display on a single screen
Includes four-wheel clamps with camera targets, steering wheel lock and wheel chocks
One-year warranty
AUTEL MAXISYS ADAS IA900AST Wheel Alignment & ADAS System Calibration Frame Specifications :
New AUTEL IA900WA Wheel Alignment & ADAS System Calibration With MSULTRAADAS Tablet Package | Emirates Keys
New AUTEL IA900WA Wheel Alignment & ADAS System Calibration With MSULTRAADAS Tablet Package | Emirates Keys
•24in Touchscreen Monitor
•Simulcast from MAXI-SYS Ultra
•MAXI-SYS Ultra Tablet Cradle With Controls
•MAXI-SYS Interface Instead of PC for Wheel Alignment
•Robotic Frame Movement
•Precise Optical Measurement With 6 High Resolution Cameras
•Self Calibrating Cameras, Always Accurate, Every Time
•Cameras Automatically Track Vehicle Height On Lift
New AUTEL IA900WA Wheel Alignment & ADAS System Calibration With MSULTRAADAS Tablet Package | Emirates Keys
AUTEL MAXI-SYS ADAS IA900AST WHEEL ALIGNMENT SOFTWARE
Vehicle inspection of tires, brakes, suspension, steering, and more. Mark service recommendations, attach photos and notes.
Live alignment reading display.
Illustrated alignment instructions, live readings, required tools, and adjustment locations display on a single screen.
IA900A ADAS CALIBRATION SOFTWARE
The industry’s fastest and most accurate frame placement in as little as a minute.
Step-by-step illustrated full-color instructions walk the user through the ADAS calibration process.
Set ADAS calibration target height with the push of a button.
AUTEL MAXI-SYS ADAS CALIBRATION Compensates for uneven floors in all directions.
FOLDING CROSSBAR
6inch MINIMUM HEIGHT
7inch MAXIMUM HEIGHT
AUTEL ADAS Packages Compare
The New AUTEL IA900WA All ADAS Systems Package, with Alignment System which also includes the MSULTRA Tablet Part Number: IA900AST
The New AUTEL ADAS IA900WA with MSULTRA Tablet Includes:
AUTEL MAXI-SYS MSULTRA Table Diagnostic Scanner Tablet with ADAS Upgrade
MS ULTRA Tablet
ADAS Upgrade Software
1. Pattern Board 0600/06
2. Patterns VW-LDW CSC0601/01 Mercedes-LDW CSC0601/02
3. Volkswagen / Audi / Porsche - LDWI CSC0601/01
4. Sliding Laser Plate
5. Mounted Tape Measure
6. Flip Up Reflector & Laser Position Ruler
7. Crossbar 0600/05
8. Push Button Power Lifter
9. Adjustable Base
10. Base Crossbar 0600/02
11. Base Holder 0600/01
12. ACC Reflector 0602/01
13. Wheel Clamp Lasers 0500/02
14. Wheel Clamps 0500/01
15. Honda - LDW CSC0601/05
16. Honda - LDW CSC0601/08-L
17. Honda - LDW CSC0601/08-R
18. Honda / IA LDW CSC0601/09
19. Nissan / Infiniti-LDW CSC0601/06-L
20. Nissan / Infiniti-LDW CSC0601/06-R
21. Toyota-LDW CSC0601/15
22. Nissan-LDW CSC0601/03-L
23. Nissan-LDW CSC0601/03-R
24. Toyota / Lexus LDW CSC0601/11
25. Mercedes-LDW CSC0601-02
26. Mitsubishi Lane Keep Target Board CSC601/22-L
27. Mitsubishi Lane Keep Target Board CSC601/22-R
28. Target Board Holder 0600/22
29. Cadillac - AVM CSC1004/06
30. Center Axis Laser 0500/04
31. Honda - AVM CSC1004/02
32. Honda - AVM CSC1004/03
33. Nissan - RCW CSC1006/03
34. Mercedes - RCW CSC1006/01
35. VW-RCW CSC0806/01
36. VW-AVM CSC0804/01
37. Radar Calibration Plate 0602/02
38. Radar Calibration Box 0605/01
39. Corner Reflector 0802/01
40. Night Vision Calibration Box 0603/01
41. Night Vision Calibration 0803/01
42. Mercedes Lane Keep Target Board CSC601/19
43. Subaru Lane Keep Target Board CSC601/17
44. Mazda Lane Keep Target Board CSC601/13-L
45. Mazda Lane Keep Target Board CSC601/13-R
46. Nissan Lane Keep Target Board CSC601/03-L
47. Nissan Lane Keep Target Board CSC601/03-R
48. Subaru LDW 3 CSC0601-17 Target Board
49. Alfa Romeo LDW CSC0601-10 Target Board
50. Toyota One Time Recognition LDW CSC0601-25 Target Board
51. Gensis LDW CSC0701-23
52. Mitsubishi AVM CSC1004-09
53. Honda LaneWatch CSC0805-02
54. Target Stand CSC0802
55. Hitachi Radar Plate CSC0802-03
56. Nissan RCW CSC1006-05
57. Toyota-AVM CSC1004-10
58. Hyundai/Kia vehicles equipped with AVM CSC1004/04
59. RCW for Mercedes CSC1006/02
60. VW/Audi ADR Calibration Plate CSC0602/08
61. Toyota LIDAR Reflector CSC802/04
62. VW/Audi LIDAR Calibration Board CSC602/04
63. Used for Toyota/ Lexus vehicles equipped with NVS CSC603/03
64. Nissan/Infiniti vehicles equipped with AVM CSC1004/11
65. Now comes Standard Frame 2.0 AUTEL Frame Distance Measuring Upgrade for Standard Frame
Digital Tape Measure Crossbar Brackets - Holds digital tape measure for faster & more accurate frame placement
Front Wheel Targets - Used with digital tape measures to find accurate distance from front axle
Placement Boards - For use on an alignment lift
Center Digital Tape Measure Bracket - Finds distance from front of car when measuring from emblem/bumper
Digital Tape Measures - Replaces manual tape measure for faster & more accurate frame placement
